Page 46 - YNX

PT8 DELUXE
Electronic tennis, badminton, and soft tennis stringing machine

SIZE Approx. 1050 mm (W) x 500 mm (D) x 1080-1270 mm (H)
WEIGHT Approx. 56 kg / 123 lb
HEIGHT RANGE 1,080 mm - 1,270 mm
PULL SPEED 9 speeds
TENSION RANGE 10-88 lbs (0.5 increments); 5-40 kg (0.2 increments + 5
PRE-STRETCH 1-20 (1% increments)
WARRANTY Electrical: 3 years; Mechanical: 3 years
ITEM CODE ESPT8DX-W
MSRP $9,499

Made in Japan

AERO COVER
Aero Cover sold separately and is not
included with the stringing machine.

ITEM CODE ESPT8DXACVR

Made in Japan

FEATURES

EFFICIENT: TENSION HEAD
The drum has been reduced and positioned closer to the turntable to reduce the amount of
string used, improving stringing efficiency.

ORGANIZED: STRING & AERO COVER
A rail placed under the work table creates a practical storage space for reels of string.

Aero Cover can be applied over the computer unit offering protection, and conveniently
expanding storage space.

USER-FRIENDLY: COMPUTER UNIT
The conductivity of the touchscreen has been adjusted to prevent malfunctions.

The system has added an option to set tension in 0.5 lbs increments while retaining the 0.2 kg
option from the previous model, allowing for even more precise stringing.

PRECISE: CLAMP
The PT8 Deluxe features an upgraded clamp, with a thinner, shorter, and more ergonomic
design. The new clamp design prevents clamps from overlapping and allows stringers to
clamp closer to the racquet frame when tensioning.

46
STRINGING MACHINES
